clay brick mixer filter mixing machine block mix for clay brick making factory

Brand Name : BBT

Model Number : TWJH550

Certification : ISO9001

Place of Origin : China

MOQ : 1 set

Payment Terms : L/C, T/T

Supply Ability : 10 set per month

Delivery Time : 10-15days

Packaging Details : filter mixer extrtuder by container sea shipment

Rotating diameter of the stirring : 550mm

Production capacity : 45-50m3/hr

Rotating speed : 30rpm

Name : clay brick mixer filter mixing machine block mix for clay brick making factory

Contact Now

Red clay brick mixer filter mixing machine block mix for clay brick making factory

clay brick mixer filter mixing machine block mix for clay brick making factory

Mixing machine filter mixer for thin-walled hollow blocks clay raw material treatment mixing equipment

TWJH550 front grid mixer extruder is a new product developed by our company on the basis of absorbing the advanced experience of similar products abroad, and it occupies a leading position among similar products in China.

The function of the front grid mixer: homogenize and mix raw materials through biaxial stirring; Through reamer extrusion, strengthen the mutual penetration of water between raw materials and improve the plasticity of materials.

It is equipped with a mesh plate to increase the resistance, thereby improving the kneading efficiency of the raw materials, and can filter the grass roots and bark in the soil, reducing the blockage of the brick machine mold and the probability of breaking the steel wire of the blank cutting machine.

Red clay brick mixer filter mixing machine block mix for clay brick making factory

clay brick mixer filter mixing machine block mix for clay brick making factory

Filter mixer of technical paramerters:

Item	TWJH-550	TWJH-750
Diameter of auger	550mm	750mm
Rotate speed for main shaft	≥30 rpm	≥30rpm
Motor Power	90+5.5 kw	132-160kw
Diameter for screen hole	Customized building	Customized building
Production capacity	45-50 m³/h	60-75 m³/h
Total weight of equipment	8900 kg	15800 kg

Filter mixer for clay brick making plant machinery

Filter mixer machine in auto brick production line
